PCI ExpressÁ÷¡¦¿î5i
NTSC
Frame grabber Board

APX-3502

CameraLink rohsÁ÷¡¦


The specification and externals of product are for the improvement and might be changed without previous notice

Features

¡üNTSC camera interface for two independent analog cameras

¡üInput resolution : 8bit/10bit(Selectable)

¡üSupports camera and board synchronization in the synchronous mode
¡üIndependent input control circuit for both synchronous and asynchronous image acquisition

¡¡¡ıSynchronous operation: Capture the image at the same timing when the board
       is in the synchronous mode

¡¡¡ıAsynchronous operation: Capture the image at the individual timing regardless
      of synchronous mode

¡ü256Mbyte of memory for the image buffer

¡üTrigger input for the image input control for each channel

¡üPCI-Express 2.0 gen2 (2.5GT/s)

¡ü LoHS Compliant

Specification

Model
APX-3502
Image Acquisition I/F
¡ıSignal format : RS-170A/NTSC monochrome video signal
¡ıInput : 2ch
¡ıSynchronous mode : Camera synchronization/ Board
    synchronization
¡ıSynchronous signal output : HD/VD
    Output level ? High impedance 5Vp-p
    75¦¸ terminated 2.5Vp-p
¡ıInput resolution : 8bits/10bits
¡ıAspect ratio : 1:1
¡ıSampling clock : 12.273MHz
¡ıImage acquisition size : 640 ¡ß 484
External trigger input
TTL 2ch(For the image input control)
Memory
256Mbyte(DDR2-667) FIFO function
System bus
x 1 PCI Express 2.0a Gen2(2.5GT/s)
Power consumption
+3.3V : 180mA
+12V : 800mA
Environment
Temperature : 0¡î to 5¡î
Humidity : 35% to 85%(non-condensing)
Dimension
167.65mm(W) x 111.15(D)mm(without connector projection)
Weight
170£ç
OS
Windows
Environmental Compliance
Windows



Panel
